Question 1:

The wavelength: C

Wavelength is the distance between two consecutive identical points, such as from crest to crest.

*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.

Question 2:

The amplitude: D

Amplitude is the maximum displacement from the rest position (the dashed center line) to a crest or trough.

*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.

Question 3:

Increasing the volume of a sound means it is louder, which corresponds to greater energy transfer.
For a sound wave, louder volume = greater amplitude (the maximum displacement of particles in the medium).

• Frequency (A) determines pitch, not loudness.

• Wavelength (C) is related to frequency and speed; changing volume doesn’t directly change it.

• Wave speed (D) depends only on the medium (temperature, pressure, etc.), not on amplitude.

So the measurement that changes to increase volume is the amplitude.

Answer: B. The amplitude.

*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.

Question 4:

Based on oscilloscope display conventions:

• Height (amplitude) → loudness (tall = loud, short = quiet)

• Number of waves in a fixed width → frequency (more waves = higher pitch, fewer waves = lower pitch)

• Wavelength is inversely related to frequency in a fixed box width (more waves = shorter wavelength, fewer waves = longer wavelength)

  A high amplitude, long wavelength sound → A (tall height, a few waves)

*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.

Question 5:

Based on oscilloscope display conventions:

• Height (amplitude) → loudness (tall = loud, short = quiet)

• Number of waves in a fixed width → frequency (more waves = higher pitch, fewer waves = lower pitch)

• Wavelength is inversely related to frequency in a fixed box width (more waves = shorter wavelength, fewer waves = longer wavelength)

  Low amplitude, high frequency sound → B (short height, many waves)

*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.

Question 6:

The name given to waves where the oscillations are in the same direction as the wave energy transfer is longitudinal waves.

Answer: longitudinal waves

*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.

Question 7:

The name given to waves where the oscillations are at right angles to the direction of wave energy transfer is transverse waves.

Answer: transverse waves

*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.

Question 8:

Among the options:

• A. Sound waves → longitudinal (oscillations parallel to energy transfer)

• B. Water waves (on the surface) → transverse (oscillations perpendicular to energy transfer; though water molecules also have some circular motion, surface waves are generally classified as transverse for basic physics purposes)

• C. Light waves → transverse (electromagnetic)

• D. Microwaves → transverse (electromagnetic)

Answer: A. Sound waves

*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.

Question 9:

The number of waves passing a point each second is the frequency.

Answer: B. frequency

*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.

Question 10:

The unit for the number of waves per second (frequency) is hertz (Hz).

Answer: D. hertz (Hz)
